ACL Race Series >> ACL Race Series Main bearing set-performance - 5M1644HX-STD

ACL Race Series Main bearing set-performance - 5M1644HX-STD

Part
Thumbnail
Thumbnail
Thumbnail
ACL Race Series logo

ACL Race Series Main bearing set-performance - 5M1644HX-STD

$108.52

Specifications
Material: Race Series (Tri-Metal)
Position: 1,2,3,4,5
Std Shaft Diam: 2.1243"/2.1251" (53.958mm/53.978mm)
Oil Clearance: TBA
Maximum Wall: 0.0980" (2.489mm)
Housing Bore: 2.3228"/2.3236" (59.000mm/59.019mm)
Max Length: 0.7280" (18.490mm)
Thrust Washers: 2T1644-STD

Description

Full Groove on #4 Position Only(0.001" Extra Oil Clearance)
