Nason Liner assembly kit - SAI4HF1-K-A-SF

Part

Nason Liner assembly kit - SAI4HF1-K-A-SF

Out Of Stock

Specifications
Piston Set:	4 x Pistons, Pins & Rings
Std Bore Size:	112.00mm
Size:	STD
Head Type:	Dish top
Piston Type:	Cast
Length:	94.50mm
Comp Height:	60.80mm - 22.10mm - 9.20mm
Combustion Bowl OD:	49.50mm
Pin Size:	36.00mm x 79.00mm
Pin Type:	Full Floating
Skirt Coating:	No
Piston to Bore:	See Label on Box
Top Ring Width:	3.00mm Half Keystone
2nd Ring Width:	2.50mm
Oil Ring Width:	4.00mm
Liner Grade:	Semi Finished
Liner Length:	180.00mm
Liner OD:	115.00mm
Flange Diameter:	121.70mm
Flange Depth:	6.10mm

Description

Suits 04/1996 On

Alfin insert
