Isuzu >> D-MAX >> TFR >> 3.0 Litre 4 Cyl 4JJ1-TCX DOHC 16v >> TFS85 06/2012 - 06/2020 2 Door Ute/Single Cab >> Mackay Bottom Radiator Lower Hose for Isuzu D-Max 3.0L Turbo Diesel (2012-2020)

Mackay Bottom Radiator Lower Hose for Isuzu D-Max 3.0L Turbo Diesel (2012-2020) Fits Isuzu D-MAX TFR TFS85 Ute/Single Cab [06/2012 to 06/2020] (3.0L 4JJ1-TCX 4 Cyl DOHC I/C Turbo CRD)

Part
Thumbnail
Thumbnail
Mackay logo

Mackay Bottom Radiator Lower Hose for Isuzu D-Max 3.0L Turbo Diesel (2012-2020)

Fitment Information:

Refer Image - Straighter Hose Position: Lower

$17.04

Specifications
Product Type: Radiator Hose
Fitting Position: Radiator, Lower / Bottom
Material: EPDM Rubber (Ethylene Propylene Diene Monomer)
Reinforcement: Aramid / Rayon Lock-Stitch Knit
Inner Diameter 1: 36 mm
Inner Diameter 2: 36 mm
Hose Length: 345 mm
Colour: Black
Temperature Rating: -40°C to 125°C (-40°F to 257°F)
Specifications Met: SAE J20R4 Type EC Class D-1 & Class D-2
Primary Application: Water and Automotive Coolant Transfer Only
Dimensions: { "Length": "360 mm", "Width": "80 mm", "Height": "70 mm" }

Tick This part will fit the following Vehicles:

Isuzu D-MAX TFR (3.0 Litre 4 Cyl 4JJ1-TCX DOHC 16v):
  • SX Space Cab TFR85 RWD Ute/Extra Cab 4 Door [11/2015 to 06/2020] 130KW With Auto or Manual Transmission With: Refer Image - Straighter Hose
  • TFR85 RWD Ute/Dual Cab 4 Door [06/2012 to 06/2020] 130KW With Auto or Manual Transmission With: Refer Image - Straighter Hose
  • TFR85 RWD Ute/Single Cab 2 Door [06/2012 to 06/2020] 130KW With Auto or Manual Transmission With: Refer Image - Straighter Hose
  • TFS85 4WD Ute/Single Cab 2 Door [06/2012 to 06/2020] 130KW With Auto or Manual Transmission With: Refer Image - Straighter Hose
  • TFS85 4WD Ute/Dual Cab 4 Door [06/2012 to 06/2020] 130KW With Auto or Manual Transmission With: Refer Image - Straighter Hose

Description

Upgrade your cooling system with the Mackay Bottom Radiator Lower Hose, engineered specifically for the Isuzu D-Max 3.0L Turbo Diesel models from 2012 to 2020. Crafted in Australia with premium EPDM rubber and reinforced with advanced Aramid/Rayon lock-stitch knit, this hose delivers exceptional durability and reliability under extreme conditions.

Designed to withstand temperatures from -40°C to 125°C and high operating pressures, the Mackay CH6033 hose meets and exceeds OEM standards (SAE J20R4 Type EC Class D-1 & D-2), ensuring superior coolant flow and optimal engine temperature control. Its precision engineering guarantees a perfect fit for Isuzu D-Max TFR85 and TFS85 variants with 130kw output, providing a straighter lower hose position for easy installation.

Key Features:

  • Premium-grade EPDM rubber construction resistant to heat, water, and ozone
  • Embeded Aramid/Rayon reinforcement for high pressure and temperature tolerance
  • Exact match or exceed OEM fit and performance specifications
  • Ideal for water and automotive coolant use only (not suitable for fuel, oil, or brake fluids)
  • Dimensions: 360mm (L) x 80mm (W) x 70mm (H), 36mm inner diameter at both ends
  • Proudly made in Australia by Mackay, a trusted name in automotive quality for over 85 years

Fitment Notice:

Compatible with Isuzu D-Max TFR and TFS 3.0L models (2012-2020, 130kw) including SX Space Cab and Space Cab variants. Not suitable for other Isuzu D-Max engines or model codes listed in the warning section.

Keep your cooling system performing at its best with Mackay’s reliable and long-lasting lower radiator hose. Order now to ensure efficient coolant flow and protect your Isuzu D-Max engine from overheating.
