Suzuki >> Swift >> SF413 >> 1.3 Litre 4 Cyl G13BA SOHC 8v >> GL AH35S 12/1990 - 09/1995 4 Door Sedan >> Nason Piston & pin set

Nason Piston & pin set Fits Suzuki Swift SF413 GL AH35S Sedan [12/1990 to 09/1995] (1.3L G13BA 4 Cyl SOHC CARB)

Part
Nason logo

Nason Piston & pin set

Out Of Stock

Specifications
Piston Set: 4 x Piston & Pins
Std Bore Size: 74.00mm
Size: 1.00mm / .040"
Head Type: Flat Top with 2 Valve Reliefs
Piston Type: Cast
Length: 56.20mm
Comp Height: 29.20mm
Pin Size: 17.00mm x 65.00mm
Pin Type: Press Fit
Skirt Coating: No
Piston to Bore: See Label on Box
Top Ring Width: 1.20mm
2nd Ring Width: 1.50mm
Oil Ring Width: 2.80mm
Ring Set: 2C4258
Size: 1.00mm Oversize

Tick This part will fit the following Vehicles:

Suzuki Swift SF310 (1.3 Litre 4 Cyl G13BA SOHC 8v):
  • Cino AB35S FWD Hatchback 4 Door [05/1994 to 12/1999] 50KW With Auto or Manual Transmission
Suzuki Swift SF413 (1.3 Litre 4 Cyl G13BA SOHC 8v):
  • Cino, GP AA35S FWD Hatchback 2 Door [05/1994 to 12/1999] 50KW With Manual Transmission
  • GL AH35S FWD Sedan 4 Door [12/1990 to 09/1995] 50KW With Auto or Manual Transmission

Description

Nason, 1.00mm Oversize
