| Specifications |
| Material: |
F780 (Tri-Metal) |
| Position: |
1,3 |
| Std Shaft Diam: |
2.4988"/2.4998" (63.470mm/63.495mm) |
| Oil Clearance: |
TBA |
| Maximum Wall: |
0.0835" (2.374mm) |
| Housing Bore: |
2.6870"/2.6880" (68.250mm/68.275mm) |
| Max Length: |
0.8690" (22.070mm) |
| Position: |
2 |
| Std Shaft Diam: |
2.4988"/2.4998" (63.470mm/63.495mm) |
| Oil Clearance: |
TBA |
| Maximum Wall: |
0.0935" (2.374mm) |
| Housing Bore: |
2.6870"/2.6880" (68.250mm/68.275mm) |
| Max Length: |
1.0580" (26.870mm) |
| Position: |
4 |
| Std Shaft Diam: |
2.4988"/2.4998" (63.470mm/63.495mm) |
| Oil Clearance: |
TBA |
| Maximum Wall: |
0.0935" (2.374mm) |
| Housing Bore: |
2.6870"/2.6880" (68.250mm/68.275mm) |
| Max Length: |
0.0869" (22.070mm) |
| Position: |
4 |
| Std Shaft Diam: |
2.4988"/2.4998" (63.470mm/63.495mm) |
| Oil Clearance: |
TBA |
| Maximum Wall: |
0.0935" (2.374mm) |
| Housing Bore: |
2.6870"/2.6880" (68.250mm/68.275mm) |
| Max Length: |
0.0869" (22.070mm) |
| Size: |
0.75mm Oversize |
