ACL Race Series >> ACL Race Series Main bearing set-performance - 5M1010H-001

ACL Race Series Main bearing set-performance - 5M1010H-001

Part
ACL Race Series logo

ACL Race Series Main bearing set-performance - 5M1010H-001

Out Of Stock

Specifications
Material: Race Series (Tri-Metal)
Position: 1,2,4,5
Std Shaft Diam: 2.7484"/2.7492" (69.809mm/69.830mm)
Oil Clearance: TBA
Maximum Wall: 0.0962" (2.443mm)
Housing Bore: 2.9417"/2.9425" (74.719mm/74.740mm)
Max Length: 0.8800" (22.350mm)
Position: 3
Std Shaft Diam: 2.7484"/2.7492" (69.809mm/69.830mm)
Oil Clearance: TBA
Maximum Wall: 0.0962" (2.443mm)
Housing Bore: 2.9417"/2.9425" (74.719mm/74.740mm)
Max Length: 1.1180" (28.400mm)
Size: 0.025mm Oversize
