ACL Race Series >> ACL Race Series Main bearing set-performance - 4M2737HX-STD

ACL Race Series Main bearing set-performance - 4M2737HX-STD

Part
Thumbnail
Thumbnail
Thumbnail
ACL Race Series logo

ACL Race Series Main bearing set-performance - 4M2737HX-STD

Out Of Stock

Specifications
Material: Race Series (Tri-Metal)
Position: 1
Std Shaft Diam: 2.4784"/2.4793" (62.951mm/62.974mm)
Oil Clearance: TBA
Maximum Wall: 0.0715" (1.817mm)
Housing Bore: 2.6238"/2.6249" (66.645mm/66.672mm)
Max Length: 0.8860" (22.500mm)
Position: 2,3
Std Shaft Diam: 2.4784"/2.4793" (62.951mm/62.974mm)
Oil Clearance: TBA
Maximum Wall: 0.0715" (1.817mm)
Housing Bore: 2.6238"/2.6249" (66.645mm/66.672mm)
Max Length: 0.7480" (19.000mm)
Position: 4
Std Shaft Diam: 2.4784"/2.4793" (62.951mm/62.974mm)
Oil Clearance: TBA
Maximum Wall: 0.0715" (1.817mm)
Housing Bore: 2.6238"/2.6249" (66.645mm/66.672mm)
Max Length: 1.1360" (28.850mm)

Description

Upper Shell Has 5 Holes (0.001" Extra Oil Clearance)
