ACL Race Series >> ACL Race Series Main bearing set-performance - 5M1538HX-STD

ACL Race Series Main bearing set-performance - 5M1538HX-STD

Part
Thumbnail
Thumbnail
Thumbnail
ACL Race Series logo

ACL Race Series Main bearing set-performance - 5M1538HX-STD

Out Of Stock

Specifications
Material: Race Series (Tri-Metal)
Position: 1,2,4,5
Std Shaft Diam: 2.3611"/2.3618" (59.971mm/59.990mm)
Oil Clearance: TBA
Maximum Wall: 0.0974" (2.475mm)
Housing Bore: 2.5591"/2.5598" (65.000mm/65.019mm)
Max Length: 0.7870" (20.000mm)
Position: 3
Std Shaft Diam: 2.3611"/2.3618" (59.971mm/59.990mm)
Oil Clearance: TBA
Maximum Wall: 0.0974" (2.475mm)
Housing Bore: 2.5591"/2.5598" (65.000mm/65.019mm)
Max Length: 0.9820" (24.940mm)

Description

Lower Has 2 Notches (0.001" Extra Oil Clearance)
