ACL Race Series >> ACL Race Series Main bearing set-performance - 5M7298H-002

ACL Race Series Main bearing set-performance - 5M7298H-002

Part
ACL Race Series logo

ACL Race Series Main bearing set-performance - 5M7298H-002

Out Of Stock

Specifications
Main Bearing Set: 5M7298H
Brand: ACL Race Series
Manufacturer: ACL
Main Bearing (c): 7299H(F)
Half Type: Upper & lower
Manufacturer: ACL
Min Std Shaft Size: 2.5588in / 64.993mm
Max Std Shaft Size: 2.5593in / 65.007mm
Min Std Tunnel Size: 2.7509in / 69.873mm
Max Std Tunnel Size: 2.7515in / 69.887mm
Max Wall At Crown: 0.0957in / 2.43mm
Max Overall Length: 1.0276in / 26.1mm
Min Vertical Oil Clearance: 0.0002in / 0.006mm
Max Vertical Oil Clearance: 0.0018in / 0.046mm
Material: F780
Main Bearing (c): 7298H
Half Type: Upper & lower
Manufacturer: ACL
Min Std Shaft Size: 2.5588in / 64.993mm
Max Std Shaft Size: 2.5593in / 65.007mm
Min Std Tunnel Size: 2.7509in / 69.873mm
Max Std Tunnel Size: 2.7515in / 69.887mm
Max Wall At Crown: 0.0957in / 2.43mm
Max Overall Length: 0.8051in / 20.45mm
Min Vertical Oil Clearance: 0.0002in / 0.006mm
Max Vertical Oil Clearance: 0.0020in / 0.05mm
Material: F780

Description

Solid Flange Bearing as Sold in the USA
