INTERCHANGE >> INTERCHANGE Piston & ring set - PKM4D56T-A-1.00

INTERCHANGE Piston & ring set - PKM4D56T-A-1.00

Part
INTERCHANGE logo

INTERCHANGE Piston & ring set - PKM4D56T-A-1.00

Out Of Stock

Specifications
Piston Set: 4 x Pistons, Pins & Rings
Std Bore Size: 91.10mm
Size: 1.00mm/.040"
Head Type: Flat Top Two Valve Reliefs
Piston Type: Cast
Length: 88.70mm
Comp Height: 48.70mm - 2.60mm - 3.00mm
Pin Size: 29.00mm x 75.00mm
Pin Type: Full Floating
Skirt Coating: Yes
Piston to Bore: See Label on Box
Top Ring Width: 2.50mm Half Keystone
2nd Ring Width: 2.00mm Half Keystone
Oil Ring Width: 4.00mm

Description

Suits Turbo Only With Oil Gallery Cooling-See Notes

Alfin Insert With Oil Gallery Cooling
