Interchange Piston & ring set - PKNTD42-0.50

Specifications
Piston Set:	6 x Pistons, Pins & Rings
Std Bore Size:	96.00mm
Size:	0.50mm/.020"
Head Type:	Flat top with two valve reliefs
Piston Type:	Cast
Length:	87.00mm
Comp Height:	50.20mm - 0.80mm - 1.70mm
Pin Size:	28.00mm x 80.00mm
Pin Type:	Full Floating
Skirt Coating:	No
Piston to Bore:	See Label on Box
Top Ring Width:	2.50mm
2nd Ring Width:	2.00mm
Oil Ring Width:	4.00mm

Description

28mm Gudgeon pin

Alfin insert
