Nason Piston & Pin Set - 4P1069-0.50

Part

Nason Piston & Pin Set - 4P1069-0.50

Out Of Stock

Specifications
Piston Set:	4 x Piston & Pins
Std Bore Size:	95.00mm
Size:	0.50mm / .020"
Head Type:	Dish Top
Piston Type:	Cast
Length:	59.30mm
Comp Height:	39.30mm - 8.60mm
Pin Size:	22.00mm x 62.00mm
Pin Type:	Full Floating
Skirt Coating:	Yes
Piston to Bore:	See Label on Box
Top Ring Width:	1.20mm
2nd Ring Width:	1.20mm
Oil Ring Width:	2.00mm
Ring Set:	2C5261 Or SDT10193
Size:	0.50mm Oversize

Description

Anodized Top & 2nd Ring Lands
