Nason >> Nason Piston & Pin Set - 4P1205-0.50

Nason Piston & Pin Set - 4P1205-0.50

Part
Nason logo

Nason Piston & Pin Set - 4P1205-0.50

Out Of Stock

Specifications
Ring Set: 2C6830 or 6830
Oil Ring Width: 4.00mm
2nd Ring Width: 2.50mm
Top Ring Width: 2.00mm
Piston to Bore: See Label on Box
Skirt Coating: No
Pin Type: Press Fit
Pin Size: 20.00mm x 62.00mm
Comp Height: 41.00mm - 1.60mm
Length: 71.00mm
Piston Type: Cast
Head Type: Dish Top
Size: 0.50mm / .020"
Std Bore Size: 87.20mm
Piston Set: 4 x Piston & Pins
